FRP Water Gully Covers

FRP Water Gully Covers

WGC, or Water Gully Cover is usually a grating used to cover the drainage gully, which can quickly and directly drain water into the gully. There is no possibility of water accumulation. It is usually used in low-lying areas, on both sides of roads, indoor vegetable markets, car washes, parking basements, etc. WGC, is a crucial part of urban infrastructure that serves to shield manholes and drainage channels. The WGC offers a dependable and long-lasting option for regulating urban water systems since it is usually constructed from robust, durable materials like cast iron or concrete.

The WGC’s made of FRP is an industrial revolution, outperforming WGC’s made of cast iron, ductile iron, and RCC. Our product have undergone extensive testing in accordance with AASHTO M306, IS 1726, and BS EN 124 standards for utility and drainage services. FIRBOTOPS WGC’s satisfy all code requirements.

Our covers are available in all common sizes and can support loads ranging from 2.5 to 60 tons (E 600). They are available in square, rectangular forms

  • SALIENT FEATURES
  • APPLICATIONS

ADVANTAGES

  • Light weight and easy to handle.
  • Antitheft as it has zero scrap value.
  • Permanent Set is zero in all sizes & load bearings.
  • Resists rusting from chemicals, sewage, and rainwater.
  • Long service life due to its high impact resistance and lack of corrosion.
  • Elevated in terms of beauty as the covers are self-pigmented & need not to be painted on a regular basis.
  • The material contains pigment that has been uv stabilized as a result, the colors are not peeling or fading from sunlight.
  • Tolerant of high temperatures.

APPLICATIONS

  • Swimming pool
  • Podium levels
  • Basement Levels for Car Parking
  • Industrial Units
  • Storm Water Drain Trenches
  • Cable Laying Trenches

WATER GULLY COVER AVAILABLE SIZES

RECTANGULAR SQUARE
• 600 mm x 450 mm (24 inch x 18 inch)
• 900 mm x 450 mm (36 inch x 18 inch)
• 900 mm x 600 mm (36 inch x 24 inch)
• 900 mm x 1200 mm (36 inch x 24 inch)
• 600 mm x 1200 mm (24 inch x 48 inch)
• 300 mm x 300 mm (12inch x 12inch)
• 450 mm x 450 mm (18inch x 18inch)
• 600 mm x 600 mm (24inch x 24inch)
• 750 mm x 750 mm (32 inch x 32inch)
• 900 mm x 900 mm (36inch x 36inch)
• 1000 mm x 1000 mm (40inch x 40inch)
• 1200 mm x 1200 mm (48inch x 48inch)
• 1500 mm x 1500 mm (60inch x 60inch)
• All sizes of manholes cover are available for Load bearing of 2.5, 5, 10, 12.5, 20, 25, 40 tons
• Any other sizes in case of quantity as per customer requirements can be supplied
• All our covers are tested as per BS EN 124: 1994 & AASHTO M306
